Sensor Fusion Platform

Customizable Platform for the next
generation of Positioning and Navigation

Multi-GNSS, Multi Frequency RTK/PPP

  • Up to 3 multi-GNSS, multi-frequency receivers
  • Precise absolute RTK positioning:
    horizontal accuracy: sigma = 0.01 m
    vertical accuracy: sigma = 0.02 m
  • Precise absolute PPP positioning:
    horizontal accuracy: sigma = 0.15 m
    vertical accuracy: sigma = 0.20 m
  • Precise absolute attitude (heading, pitch, roll):
    sigma = 0.25° for 1 m distance between the GNSS antennas

Inertial Sensor

  • 3D-Gyroscope, 3D-Accelerometer, Magnetometer, Barometer, Thermometer
  • High data-rate (up to 140Hz)
  • Electively consumer-grade or industrial-grade IMU
  • On request, integration of customer used IMU (e.g. tactical-grade IMU)

Vehicle Data

  • Using Odometry / Steering / Lane-Detection information
  • Timestamps for customer’s vehicle-data by the ANavS framework
  • Supported Interfaces: CAN, Ethernet, UART

Computer Vision

  • Using Monocular- or Stereo-Cameras
  • Visual-Inertial Odometry
  • Online/Offline Map-Building and Localization
  • On request, integration of customer used Camera

Local Positioning System

  • For partially Indoor-Navigation or extremely poor GNSS-visibility
  • Especially for Robotic Solutions
  • On request, integration of customer used LPS

Lidar

  • Electively 2D- or 3D- Lidar equipment
  • Velocity information for better performance in regions with GNSS-outages
  • Online/Offline semantic Map-Building and Localization
  • On request, integration of customer used Lidar-System

Products

The next Generation of Positioning and Navigation for mass-market applications requires affordable hardware-costs and accuracy in all situations with highest reliability. This can’t be done with only single sensor-solutions. The ANavS® Multi-Sensor fusion with its tight-coupling technology brings these requirements for new autonomous solutions together.

Learn more

Solutions

Our solutions are used in Automotive, Robotic, Maritime, UAV and Surveying applications. Each customer application needs a different sensor setup. ANavS® assists and advises the customer to obtain the perfect solution.

Learn more

Configurator

With our configurator you can customize your system for your project requirements. Start your quote and we are able to make you an offer best suited for your visions

Learn more

Outstanding Performance of ANavS® Sensor Fusion Platform
